| Part | TP6806L-NB1 | TP6806L-PB1 | TP6816-CB1 | TP6816-DB1 | TP6817-CC1 | TP6817-DC1 | TP6815-CA1 | TP6815-DA1 |
| Package | EPQFN 88L, 10*10 | EPQFN 88L, 10*10 | TQFP_128, 14*14 | TQFP_128, 14*14 | TQFP_128, 14*14 | TQFP_128, 14*14 | TQFP_128, 14*14 | TQFP_128, 14*14 |
| HD-TVI/AHD/CVI | 6 | 6 | 6 | 6 | 6 | 6 | 5 | 5 |
| Diagnostic In | 5 | 5 | 5 | 5 | 5 | 5 | 4 | 4 |
| RGB888 in | x | x | 1 | 1 | 1 | 1 | 1 | 1 |
| BT.1120_16 in | 1 | 1 | 2 | 2 | 2 | 2 | 1 | 1 |
| BT.656/BT.1120_8 in | 2 | 2 | 4 | 4 | 4 | 4 | 3 | 3 |
| BT601 in | 8/16bits | 8/16bits | 8/16bits | 8/16bits | 8/16bits | 8/16bits | 8/16bits | 8/16bits |
| LVDS in | x | x | 1 | 1 | 1 | 1 | x | x |
| Mipi-CSI in | x | x | x | x | x | x | 1 | 1 |
| LVDS_Tx Channels | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 |
| Primary TTL Panel(RGB888/RGB666) | x | x | y | y | y | y | y | y |
| Video Mux Out | 8bits*1 | 8bits*1 | 8/16bits*1 + 8bits*1 | 8/16bits*1 + 8bits*1 | 8/16bits*1 + 8bits*1 | 8/16bits*1 + 8bits*1 | 8bits*1 | 8bits*1 |
| Max resolution | 1366*768 | 1366*768 | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 |
| Font OSD | Flexible size | Flexible size | Flexible size | Flexible size | Flexible size | Flexible size | Flexible size | Flexible size |
| SPI OSD | 4*2 layer | 4*2 layer | 4*2 layer | 4*2 layer | 4*2 layer | 4*2 layer | 4*2 layer | 4*2 layer |
| Horizontal Fisheye Correction | y | y | y | y | y | y | y | y |
| Audio process | 8051 | 8051 | x | x | x | x | y | y |
| MCU | 8051 | 8051 | 8051 | 8051 | 8051 | 8051 | 8051 | 8051 |
| AECQ 100 | x | y | x | y | x | y | x | y |
